Product Details:
|
| Type: | Explosion-proof Diesel Type | Working Form: | 6cylinder Water Cooling 4 Stroke |
|---|---|---|---|
| Fuel Type: | Light Diesel | Cyliner Dimension: | 6x114x145mm |
| Total Piston Displacement: | 8.9L | Cylinder Liner Type: | Wet |
| Rated. Power: | 200-260kw | Max. Torque(N.m)/speed(r/min): | 550N |
| Displacement: | 1450/1500 | Emission Level: | Eur.III (Non-road) |
| Cooling Form: | Closed Forced Circulation Water Cooling | Start Mode: | Electric/Air Start |
| Protect Form: | Electric Protection Device | Flame Arrester Structure: | Fence Type |
| High Light: | Explosion Proof Engine 4 Cylinders,Water Cooled Explosion Proof Engine |
||
Diesel explosion-proof engine 4 cylinders type Water Cooled for Zone 2
Diesel Exposion Proof Engine product Detailed Specification:
| Model | KC61147DZL(X)FB | |
| Type | Inline-Six, water-cooling,four stroke | |
| Firing Order | 1-5-3-6-2-4 | |
| Cyliner N.x bore (mm) xStroke(mm) | 6x114x145 | |
| Total Piston Displacement | 8.9 | |
| Cylinder Liner Type | Wet | |
| Oil Working Pressure(kPa) | 70-517 | |
| Starting Form | Electric/ Pneumatic | |
| Protect Form | Electric protect | |
| Flame Arrester Structure | Fence Type | |
| Rated Rolling Speed(r/min) | 2100 | |
| Rated Power(kw) | 200-260 | |
| Min. No-live load Speed(Idling)(r/min) | 800 | |
| Max. Torque(N.m)/speed(r/min) | 1450/1500 | |
| Min. Working Speed(r/min)/Torque(N.m) | 1300/1350 | |
| Max. No-live Load Speed(r/min) | 2280 | |
| Net Weight(kg) | 880 | |
| Emission Level | Non-Road Eur.III | |
| Dimension(LxWxH) | 1500x870x1100mm | |
| Cooling Form | water cooling | |
| Lubrication Mode | Combined Type | |
Products Description:
High pressure common rail diesel engine is a fuel supply machine that completely separates the generation of injection
pressure and the injection process in the closed-loop system composed of high-pressure oil pump, pressure sensor and
electronic control unit (ECU). The high-pressure fuel is delivered to the common fuel supply pipe (rail) by the high-pressure
oil pump, which is controlled by the oil pressure in the common fuel supply pipe, so that the pressure of the high-pressure
fuel pipe has nothing to do with the engine speed, which can greatly reduce the change degree of the diesel engine fuel
supply pressure with the engine speed
